Digi SM-720 - Firmware Upgrade; Bootloader Downloading

SM720 Service Manual Edition 5
72
9. FIRMWARE UPGRADE
9.1 Bootloader Downloading
The software use for Boot loader downloading to scale is Flash Development Toolkit 3.1.
1. PC to scale via RS232C interface.
Procedure Picture
1) Double click open the [Flash Development Toolkit 3.1] software.
2) When Option icon appears, click the [Cancel].
3) From the Option Menu, select the [File Æ Open An S-Record…].
RS232 Cable
