Digi SM-720 - Disassembly Procedures; Pole Type Disassembly

SM720 Service Manual Edition 5
56
7.2 Bench Type
A
SSY AA (PLATER SUPPORT)
PLATTER SUPPORT ASSY
TOP COVER
KEYBOARD ASSY
SWITCHING PS TZD200/JA
ELEC BLK (SM500V2 AC PWR)
BRACKET AB
(
FRONT COVER
)
MAINBOARD
PRINTER KIT
CASSETTE KIT
PRINTER DOOR COVER
ETHERNET ASSY
LOADCELL
(
NMB C2G1-30K-S23
)
ELEC BLK
(
SM300 A/D-1
)
DISPLAY ASSY
BRACKET DQ
(
NEW DIECAST
,
MB COV
)
BRACKET BZ
(
M/B SEAL
)
FRONT DOOR ASSY
SUPPORT AA
(LC DIECAST TOP)
1
2
3
1
4
5
6
