SM720 Service Manual Edition 5

8. DISASSEMBLY

8.1 Pole Type Disassembly

101

102

104

103

Screw Type:

101- Flat Head M4X16 (4pcs)

102- Sems B M4X10 (4pcs)

103- Flat Head M3X5 (3pcs)

104- Truss Head M4X6 (2pcs)
