SM720 Service Manual Edition 5
42
5.2.2 Adjustment
5.2.2.1 Peel Sensor setting
Procedure Picture
1) In [Operation Menu] mode, press and hold [Re-zero] and press
[0][8][9][3] to go to [Maintenance Screen].
2) Touch [Self Diagnostic] to go to self diagnostic mode.
3) In Self Diagnostic mode, press arrow key
to scroll down menu,
then press [Printer Sensor].
4) Press
(Print) key to Auto Detect peel sensor setting and touch
panel will go back to Self Diagnostic menu. After finish, test label
printing and ensure the sensor will be detect properly for label.
To Next Page
