DigiDesign Control 24 User Manual

Control|24 Guide16
Output
Three of the 25-pin D-Sub connectors provide
output from Control|24 for recording and mon-
itoring.
LINE OUT TO PRO TOOLS 1–8 and LINE OUT TO
PRO TOOLS 9–16 Provide outputs from the 16
Control|24 mic preamps (in two banks of eight
channels each), to connect to Pro Tools audio
interface inputs for recording through the Con-
trol|24 mic preamps.
MONITOR SPEAKERS OUT Provides eight chan-
nels of Control|24 output, to connect to speak-
ers for stereo and multichannel monitoring.
These outputs are controlled by the Control
Room Monitor section.
LINE OUT TO PRO TOOLS 1–8
Channel Signal (mic preamp)
1
Line Output #1
2
Line Output #2
3
Line Output #3
4
Line Output #4
5
Line Output #5
6
Line Output #6
7
Line Output #7
8
Line Output #8
LINE OUT TO PRO TOOLS 9–16
Channel Signal (mic preamp)
1
Line Output #9
2
Line Output #10
3
Line Output #11
4
Line Output #12
5
Line Output #13
6
Line Output #14
7
Line Output #15
8
Line Output #16
SPEAKERS OUT
Channel Signal
1
Control Room Output, MAIN Left
(left front)
2
Control Room Output, MAIN Right
(right front)
3
Control Room Output,
Center
4
Control Room Output,
Sub
5
Control Room Output,
Left Surround
6
Control Room Output,
Right Surround
7
Control Room Output, ALT Left
8
Control Room Output, ALT Right

DigiDesign Control 24 Specifications

General

Channels	24
Faders	24 motorized 100mm faders
Connectivity	Ethernet
Compatibility	Pro Tools
Audio Interface	No built-in audio interface
EQ	4-band EQ per channel
MIDI I/O	Yes
Footswitch I/O	Yes
Power Supply	Internal
