C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 97 –
Show Information Displays port connection status 149
Mirror 150
Add Sets the source and target ports for mirroring 150
Show Shows the configured mirror sessions 150
Statistics Shows Interface, Etherlike, and RMON port statistics 156
Chart Shows Interface, Etherlike, and RMON port statistics 156
Cable Test Performs cable diagnostics for selected port to diagnose any cable
faults (short, open etc.) and report the cable length
160
Trunk 162
Static 163
Configure Trunk 163
Add Creates a trunk, along with the first port member 163
Show Shows the configured trunk identifiers 163
Add Member Specifies ports to group into static trunks 163
Show Member Shows the port members for the selected trunk 163
Configure General 163
Configure Configures trunk connection settings 163
Show Information Displays trunk connection settings 163
Dynamic 166
Configure Aggregator Configures administration key and timeout for specific LACP
groups
166
Configure Aggregation Port 163
Configure 163
General Allows ports to dynamically join trunks 166
Actor Configures parameters for link aggregation group members on the
local side
166
Partner Configures parameters for link aggregation group members on the
remote side
166
Show Information 172
Counters Displays statistics for LACP protocol messages 172
Internal Displays configuration settings and operational state for the local
side of a link aggregation
173
Neighbors Displays configuration settings and operational state for the
remote side of a link aggregation
175
Configure Trunk 166
Configure Configures connection settings 166
Show Displays port connection status 166
Show Member Shows the active members in a trunk 166
Statistics Shows Interface, Etherlike, and RMON port statistics 156
Table 6: Switch Main Menu (Continued)
Menu Description Page
