Draytek VigorAP 906 User Manual

43
Isolate members with
IP
The default setting is “Disable”.
If it is enabled, VigorAP will isolate different wireless clients according
to their IP address(es).
WMM Capable
To apply WMM parameters for wireless data transmission, please click
the Enable radio button.
APSD Capable APSD (automatic power-save delivery) is an enhancement over the
power-save mechanisms supported by Wi-Fi networks. It allows
devices to take more time in sleeping state and consume less power
to improve the performance by minimizing transmission latency.
The default setting is Disable.
MAC Clone
(for 2.4GHz only)
Click Enable and manually enter the MAC address of the device with
SSID 1. The MAC address of other SSIDs will change based on this
MAC address.
After finishing this web page configuration, please click OK to save the settings.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
