Draytek VigorAP 906 User Manual

83
Item Description
Enable Check it to enable the RADIUS server settings.
Comments Enter a brief description for this profile.
Primary Server Enter the IP address of the RADIUS server.
Secret The RADIUS server and client share a secret that is used to
authenticate the messages sent between them. Both sides must be
configured to use the same shared secret. The maximum length of the
shared secret you can set is 36 characters.
Authentication Port The UDP port number that the RADIUS server is using. The default
value is 1812, based on RFC 2138.
Retry Set the number of attempts to perform reconnection with the RADIUS
server.
Save and Next Click to access into next page.
After finishing this web page configuration, please click Save and Next for the next setting page.
(3) Whitelist Settings
Users are allowed to send and receive the traffic that satisfies whitelist settings. IPs under the
whitelist will not be redirected to other website (URL).

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
