c HELP Mode Function and Operation Procedures
chap.7
(1)
Adjusting/Checking the master feed section
(2 pages in total)
Page 1 :
2
Check operation.
MASTER FEED STEPPING MOTOR / MASTER FEED CLUTCH / CUTTER MOTOR /
THERMAL HEAD UP/DOWN MOTOR
2
Checking sensors/switches.
MASTER FEED COVER SWITCH / MASTER TOP SENSOR / THERMAL HEAD UP/DOWN SENSOR
¡ Operation procedure
1.
3.
Check the following sensors and switches.
Checking sensors/switches.
2.
Check operation.
¡
After checking the cutter motor
operation, be sure to return the
cutter blade to the operation side.
step 4.
a
Press the
(STOP)
key.
Enter
“
008
”
by the
NUMERIC
keys and then press the
(PRINT)
key.
Call the HELP mode
“
H-008
”
.
To Next Page
