DURKOPP ADLER 1767 Service Instructions

Maintenance
110 Service Instructions 1767 - 00.0 - 12/2016
20.2.1 Checking the oil level
Fig. 78: Checking the oil level
To check the oil level:
1. Check the oil level indicator every day:
• The oil level must be between the minimum level mark (3) and the
maximum level mark (2).
Topping off the oil
To top off the oil:
1. Pour in oil through the refill opening (1).
 Add oil up to but not past the maximum level marking.
(1) - Refill opening
(2) - Maximum level marking
(3) - Minimum level marking
MAX
MIN
③
①
②
