3.6 Setting the handwheel into position
For some settings, the graduated scale on the handwheel has to be
moved to a certain position.
Fig. 14: Setting the handwheel into position
To set the handwheel into position:
1. Turn the handwheel until the required number on the graduated
scale (2) is next to the marking (1).
(1) - Marking (2) - Graduated scale
