Working basis
Service Instructions 1767 - 00.0 - 12/2016 15
Tilting the machine head
To tilt the machine head:
1. Tilt the machine head as far as it will go.
Erecting the machine head
To erect the machine head:
1. Erect the machine head.
3.3.2 Removing and placing the arm cover
Fig. 2: Removing and placing the arm cover
Removing the arm cover
To remove the arm cover:
2. Loosen the screws (1).
3. Remove the arm cover (2).
The arm cover and control panel holder are removed jointly.
Placing the arm cover
To place the arm cover:
4. Place arm cover (2) and control panel holder.
(1) - Screws
(2) - Arm cover
(3) - Slots
