3.3 Removing the covers
For many types of setting work, you will have to remove the machine
covers first in order to access the components.
This chapter describes how to remove and then refit the individual covers.
The text for each type of setting work then specifies only the cover that
needs to be removed at that particular time.
3.3.1 Access to the underside of the machine
In order to access the components at the machine bottom section, you
must first tilt the machine head.
Fig. 1: Access to the underside of the machine
CAUTION
Risk of injury from moving parts!
Crushing possible.
Switch off the machine before removing and
re-placing covers.
