Programming
108 Service Instructions 867-M PREMIUM - 03.0 - 05/2017
20.5.2 Setting the Thread clamp parameter (Thread Clamp)
Various settings can be made for the thread clamp. The possibilities are
explained in more detail in the table.
PWM Config Pulse width modulation
Power supply to the magnet for the thread cutter.
t1 [ms]
Activation duration of the thread cutter in time period t1.
(Value range 000 – 1000 [ms])
DtyC. t1 [%]
Duty cycle in time period t2
(Value range 000 – 1000 [%])
t2 [s]
Activation duration of the thread cutter in time period t2.
(Value range 000 – 1000 [ms])
DtyC. t2 [%]
Duty cycle in time period t2
(Value range 000 – 1000 [%])
Menu item Setting option
Menu item Setting options
Mode Various modes (1 to 10) are available; explanations can be found in
the Parameter list 867-M PREMIUM.
Clamp Angle ON/OFF
Position for activating and deactivating the thread clamp.
(Value range 000 – 359)
Foot Angle ON/OFF
Position for lifting/lowering the sewing feet, to release a thread jammed
underneath.
(Value range 000 – 359)
Height
Lifting height of the sewing feet.
(Value range 01.0 – 12.0)
Option Mode of thread clamp
0 – at seam start only
1 – at seam start and during reversal
2 – at seam start and during sewing foot lift
3 – at seam start and during reversal and sewing foot lift
