Programming
118 Service Instructions 867-M PREMIUM - 03.0 - 05/2017
20.5.18 Setting the Segment length (Mode Seg.Size) parameter
Various settings can be made for the segment length. The possibilities are
explained in more detail in the table.
20.5.19 Setting the Threading mode (Threading) parameter
Various settings can be made for the threading mode. The possibilities are
explained in more detail in the table.
20.6 User configuration (User config.) submenu
Settings can be made here that are designed to make working on the
machine in various external conditions easier for the operator.
The parameters are explained in more detail in the subchapters.
The menu is divided into the following submenus:
Menu item Setting options
BySize Seam sections are measured via the length specification (in mm).
ByCount Seam sections are measured via the stitch count.
Menu item Setting options
Down The sewing foot is lowered in threading mode.
Up The sewing foot is lifted in threading mode.
Pedal The sewing foot can be lifted or lowered with the pedal in threading
mode.
Parameter Explanation Reference
Language Language selection p. 119
ParameterView Parameter view p. 119
Input Config Configuration of the inputs p. 120
Output Config Configuration of the outputs p. 121
StitchFunctions Stitch functions p. 122
Programs Programs p. 123
Jog-Dial Electronic handwheel p. 123
Lock Access rights p. 124
Contrast Contrast p. 125
Brightness Brightness p. 125
