Programming

120 Service Instructions 867-M PREMIUM - 03.0 - 05/2017

20.6.3 Setting the Input configuration (Input Config) parameter

Configure and allocate the inputs here. The table shows the inputs and

their allocation.

Machine input signal Input

Buttons on the button bar

S1 X120T.3

S2 X120T.16

S3 X120T.4

S4 X120T.17

S5 X120T.5

S6 X120T.18

Knee button S1 X120T.15

Knee button S2 X120T.2

Electronic handwheel S1 X100B.15

Operation lock input

(input on the circuit board)

X120B.2

DB3000 IN (X23)

(input on the circuit board)

X120B.15

Light barrier (X21) (optional) X100B.4

Additional button S1 (optional) X120B.16

Additional button S2 (optional) X120B.4
