Programming
110 Service Instructions 867-M PREMIUM - 03.0 - 05/2017
20.5.3 Setting the Speed (Speed) parameter
Various settings can be made for the speed. The possibilities are explained
in more detail in the table.
20.5.4 Setting the Stop positions (Stop Positions) parameter
Various settings can be made for the stop positions. The possibilities are
explained in more detail in the table.
20.5.5 Setting the Sewing foot (Foot) parameter
Various settings can be made for the sewing foot. The possibilities are
explained in more detail in the table.
Menu item Setting options
Max. speed Maximum permissible speed; it can no longer be exceeded on the
operator level.
(Value range 0500 – 3800 [rpm], depending on subclass)
Min. speed Minimum speed at which an individual stitch is made; a lower speed is
no longer possible on the operator level.
(Value range 050 – 400 [rpm])
Pos. Speed Position speed; the last stitch is made slower during stopping of the
sewing procedure.
(Value range 010 – 700 [rpm])
Soft Speed Speed for the soft start.
(Value range 0010 – 1000 [rpm])
N Stitches Number of stitches to be made during a soft start.
(Value range 00 – 10)
Menu item Setting options
StopIdle° Stop position after thread cutting (reversal position).
Value range (000 – 359)
StopTop° Holding position of the needle outside of the material.
Value range (000 – 359)
StopBottom° Holding position of the needle in the material.
Value range (000 – 359)
Threading° Position for the proper function of the threader, e.g. with thread lever at
top dead center.
Value range (000 – 359)
Menu item Setting options
Max Height Maximum lift height that the system may lift the sewing feet.
(Value range with standard thread cutter 01.0 – 20.0 [mm])
(Value range for short thread cutter 01.0 – 18.0 [mm] due to raised
throat plate)
Motor Speed Speed at which the sewing feet will be lifted.
(Value range 01 – 60)
