Maintenance

Service Instructions 867-M PREMIUM - 03.0 - 05/2017 145

Fig. 113: Cleaning

Areas particularly susceptible to soiling:

• Cutter on the winder for the hook thread (4)

• Area under the throat plate (3)

• Hook (2)

• Area around the needle (1)

To clean the machine:

1. Remove any lint and thread remnants using a compressed air gun or

a brush.

(1) - Area around the needle

(2) - Hook

(3) - Area under the throat plate

(4) - Cutter on the winder

①

②

④

③
