DURKOPP ADLER 867-M Premium - 4 Machine Description

Working basis
Service Instructions 867-M PREMIUM - 03.0 - 05/2017 15
Fig. 1: Calling up the service routine (1)
6. Press button 7.
 A request appears to press the Service Stop button.
Fig. 2: Calling up the service routine (2)
7. Press the Service Stop button.
 The machine moves to the programmed position and is switched off.
The button lights up.
The display shows the information that the Service Stop is active.
Fig. 3: Calling up the service routine (3)
8. Make the required settings.
9. Press the Service Stop button.
 The power is switched on again.
The button turns off.
The display shows a warning.
Fig. 4: Calling up the service routine (4)
10. Press the OK button.
 You are now in the service menu again.
11. To exit the menu, press the ESC button.
Stroke
0.0
Equal
Stroke
0 30
Stroke
Equal
Stroke
Press Service Stop!
Stroke
Equal
Stroke
Service Stop active!
Stroke
Equal
Stroke
Lower Foot - Press OK!
