Setting the feed dog
42 Service Instructions 867-M PREMIUM - 03.0 - 05/2017
To set the compensating weight:
1. Tilt the machine head ( p. 16).
1. Move the handwheel into the 210° position.
2. Unscrew the threaded pin (1) and leave the hex key inserted in the
threaded pin.
3. Turn the compensating weight (2) such that the threaded pin (1) is
parallel to the base plate (3). Use the hex key inserted in the threaded
pin as a means of orientation.
4. Tighten the threaded pin (1).
