Sewing feet
60 Service Instructions 867-M PREMIUM - 03.0 - 05/2017
5. Place a 5 mm distance piece (e.g. locking pin 0367 105950) between
the presser foot and throat plate.
6. Loosen the screw (2).
7. Turn the control cam (1) to the position indicated above.
8. Peg it in place with the cylinder pin (3).
9. Tighten the screw (2).
10. Assemble the spring (5).
Sewing foot pressure
The sewing foot pressure is set via the program parameters.
The correct sewing foot pressure depends on the sewing material:
• Lower pressure for soft materials, e.g. fabric
• Higher pressure for durable materials, e.g. leather or laminate
Proper setting
The sewing material does not slip and is correctly transported.
Sewing foot lift
The sewing foot lift is set via the program parameters.
When the pedal is pressed back halfway, the sewing feet can be raised
during sewing, e. g. to move the sewing material.
When the pedal is pressed completely back, the sewing feet will be raised
after the thread is cut so that the sewing material can be removed.
Proper setting
The distance between the raised sewing feet and the throat plate is preset
to 20 mm on delivery.
This distance is preset to 18 mm on machines with a short thread cutter.
