Maintenance, 10h
4812164901_A.pdf 2022-11-14
Fig. Hood
1. Cooling air openings
1
Air circulation - Check
Check that there is free air circulation through the
hood’s air openings.
Scrapers, spring-action
Checking - Adjustment
Fig. Spring-action scrapers
1. Scraper blade
2. Nut
3. Spring
2
3
1
Loosen the nut (2) to allow the spring to create the
scraper’s contact force. When transporting the
machine, lift up the scraper and tighten the nut (2).
96
