Operation
4812164901_A.pdf2022-11-14
Interlock
The roller is equipped with Interlock.
If you get up from the driver’s seat while driving
forwards/backwards, the buzzer emits a continuous
sound and the forward drive is switched off after 4
seconds.
If the control is in neutral when the operator stands up,
a buzzer will beep until the parking brake button is
activated.
If the parking brake remains inactive, the drive turns
off after 4 seconds.
If for any reason the forward/reverse lever is moved
out of neutral when the operator is not sitting down
and the parking brake button has not been activated,
the forward drive will be switched off immediately and
the buzzer will sound continuously. The parking brake
must be activated in order to restart forward drive by
releasing the parking brake again.
Sit down for all operations!Sit down for all operations!
Operator position
1
4, 5
2
Fig. Operator's seat
1. Seatbelt
2. ROPS
4. Rubber element
5. Anti-slip
If a ROPS (Roll Over Protective Structure) or a cab is
fitted to the roller, always wear the seat belt (1)
provided and wear a protective helmet.
Always replace the seat belt (1) if it shows signs of
wear or has been subjected to excessive strain.
Always replace the seat belt (1) if it shows signs of
wear or has been subjected to excessive strain.
Check the ROPS for damage. If damage is
discovered, contact the nearest person
responsible for further action
Check the ROPS for damage. If damage is
discovered, contact the nearest person
responsible for further action
Machines with folding ROPS must always be
operated with the ROPS raised and locked in
position.
Machines with folding ROPS must always be
operated with the ROPS raised and locked in
position.
Never use the forward/reverse levers as a handle
when mounting or disembarking from the roller.
Never use the forward/reverse levers as a handle
when mounting or disembarking from the roller.
63
