Dynapac CC900 e - Instruments;Controls; Locations - Control Panel and Controls

Machine description
4812164901_A.pdf 2022-11-14
Instruments/Controls
Locations - Control panel and controls
4
1. Instrument cover 6. Emergency stop 11. * Hazard indicators1. Instrument cover 6. Emergency stop 11. * Hazard indicators
2. Document storage 7. Parking brake 12. * Driving lights2. Document storage 7. Parking brake 12. * Driving lights
3. Ignition key, instrument
panel
8. Membrane panel/Function keys 13. * Direction selector /
indicator
3. Ignition key, instrument
panel
8. Membrane panel/Function keys 13. * Direction selector /
indicator
4. Battery status light 9. Control panel/Display 14. Seat switch4. Battery status light 9. Control panel/Display 14. Seat switch
5. Battery ON/OFF 10. Forward/Reverse lever5. Battery ON/OFF 10. Forward/Reverse lever
* = Optional * = Optional
2
Fig. Operator's
station
3
1
14
10
5
11
12
13
6
7
8
9
