Maintenance - Lubricants and symbols

4812164901_A.pdf 2022-11-14

Maintenance symbols

BatteryBattery

Hydraulic reservoir, level SprinklerHydraulic reservoir, level Sprinkler

Hydraulic fluid, filter Sprinkler waterHydraulic fluid, filter Sprinkler water

Drum, oil level RecyclingDrum, oil level Recycling

Lubricating oilLubricating oil
