Operation
4812164901_A.pdf2022-11-14
Interlock/Emergency stop/Parking brake -
Check
The interlock, emergency stop and parking brake must
be checked daily before operating.
The interlock, emergency stop and parking brake must
be checked daily before operating.
The interlock function is checked by the operator
standing up from the seat when the roller is moving
very slowly forwards/backwards. (Check in both
directions). Hold the steering wheel firmly and brace
yourself for a sudden stop. The buzzer sounds and
after 4 seconds the drive is switched off and the
brakes are activated.
The interlock function is checked by the operator
standing up from the seat when the roller is moving
very slowly forwards/backwards. (Check in both
directions). Hold the steering wheel firmly and brace
yourself for a sudden stop. The buzzer sounds and
after 4 seconds the drive is switched off and the
brakes are activated.
Check the function of the emergency stop by pressing
the emergency stop button when the roller is moving
slowly forward/backward. (Check in both directions).
Hold the steering wheel firmly and brace yourself for a
sudden stop. The brakes are applied, the forward drive
and the machine is switched off.
If a malfunction is detected when testing the
emergency stop, rectify the fault immediately.
Check the function of the emergency stop by pressing
the emergency stop button when the roller is moving
slowly forward/backward. (Check in both directions).
Hold the steering wheel firmly and brace yourself for a
sudden stop. The brakes are applied, the forward drive
and the machine is switched off.
If a malfunction is detected when testing the
emergency stop, rectify the fault immediately.
1
2
Fig. Instrument panel
1. Parking brake
2. Brake warning lamp
Parking brake - Check
Check the function of the parking brake by
activating the parking brake (1) when the roller is
moving very slowly forwards/backwards. The
parking brake indicator (2) lights up on the
left-hand side of the display when the parking
brake is activated. (Check in both directions). Hold
the steering wheel and brace yourself for a sudden
stop when the brakes are activated.
Check the function of the parking brake by
activating the parking brake (1) when the roller is
moving very slowly forwards/backwards. The
parking brake indicator (2) lights up on the
left-hand side of the display when the parking
brake is activated. (Check in both directions). Hold
the steering wheel and brace yourself for a sudden
stop when the brakes are activated.
If a malfunction is detected when testing the
parking brake, rectify the fault immediately.
If a malfunction is detected when testing the
parking brake, rectify the fault immediately.
67
