Securing CC900 e/1000 e for loading
Securing vibratory roller CC900 e/1000 e from
Dynapac loaded on a trailer for transport by road and
on the Baltic Sea/North Sea (Sea area A/B).
Direct of travel
1 - 2 = double lashings, i.e. one lashing with two parts secured to two different lashing mounts,
symmetrically located on the right and left sides.
1 - 2 = double lashings, i.e. one lashing with two parts secured to two different lashing mounts,
symmetrically located on the right and left sides.
3 = rubber fiction pads3 = rubber fiction pads
The lashings' permitted distance interval in metersThe lashings' permitted distance interval in meters
(1 - 2: Double lashings, LC at least 1.6 tonnes (1600 daN)(1 - 2: Double lashings, LC at least 1.6 tonnes (1600 daN)
Double L
1
Double L
2
Double L
1
Double L
2
0,3 - 2,5 0,1 - 2,50,3 - 2,5 0,1 - 2,5
L
1
- L
3
are the longitudinal distances between the lashing points on the roller and lashing points on the platform.L
1
- L
3
are the longitudinal distances between the lashing points on the roller and lashing points on the platform.
