Dynapac D.ONE - Page 177

Code Fault reaction Description of fault Possible cause Ter-
minal
on
BLM
Input
code
for
diag-
nose
5060 Output switched
off, no potential
15 on machine,
control is
working, engine
is stopped or
cannot be started
Output relay K 11, change-
over of potential 15
Too high current flow out of
this output
Output was switched off!
Excessive current flow in cur-
rent path, probably because of
a defective coil or a short cir-
cuit to ground
X3:07 -
5061 Output switched
off, no potential
15 on machine,
control is
working, engine
is stopped or
cannot be started
Output relay K 11, change-
over of potential 15
Short-circuit current flow out
of this output
Output was switched off!
Short circuit to ground in the
current path
Lines rubbed through
X3:07 -
5062 Output switched
off, no potential
15 on machine,
control is
working, engine
is stopped or
cannot be started
Output relay K 11, change-
over of potential 15
No or too low current flow
out of this output
Wire breakage in current path
Current path connected to
+12V
X3:07 5060
5061
5062
5063 Output switched
off, no potential
15 on machine,
control is
working, engine
is stopped or
cannot be started
Output relay K 11, change-
over of potential 15
Although the output is
switched off, voltage is
present
Current path connected to
+12V
X3:07 5060
5061
5062
5070 Output switched
off, engine
cannot be started
Output relay K 39, starter
Too high current flow out of
this output
Output was switched off!
Excessive current flow in cur-
rent path, probably because of
a defective coil or a short cir-
cuit to ground
X3:06 -
5071 Output switched
off, engine
cannot be started
Output relay K 39, starter
Short-circuit current flow out
of this output
Output was switched off!
Wire breakage in current path
Current path connected to
+12V
Lines rubbed through
X3:06 -
5072 Output switched
off, engine
cannot be started
Output relay K 39, starter
No or too low current flow
out of this output
Wire breakage in current path
Current path connected to
+12V
X3:06 5070
5071
5072
5073 All outputs
switched off,
engine stopped,
safety relay
switched off
Output relay K 39, starter
Although the output is
switched off, voltage is
present
Current path connected to
+12V
X3:06 5070
5071
5072
Appendix – List of fault codes
D.ONE
177
