Dynapac D.ONE - Page 178

Code Fault reaction Description of fault Possible cause Ter-
minal
on
BLM
Input
code
for
diag-
nose
5080
5085
Output switched
off, horn cannot
sound
Output horn, H 07
Too high current flow out of
this output
Output was switched off!
Excessive current flow in cur-
rent path, probably because of
a defective coil or a short cir-
cuit to ground
X3:08
X3:36
-
5081
5086
Output switched
off, horn cannot
sound
Output horn, H 07
Short-circuit current flow out
of this output
Output was switched off!
Short circuit to ground in the
current path
Lines rubbed through
Horn defective
X3:08
X3:36
-
5082
5087
Output switched
off, horn cannot
sound
Output horn, H 07
No or too low current flow
out of this output
Wire breakage in current path
Current path connected to
+12V
X3:08
X3:36
5080
5081
5082
5083
5088
Horn may sound
continuously
Output horn, H 07
Although the output is
switched off, voltage is
present
Current path connected to
+12V
X3:08
X3:36
5080
5081
5082
5090 Machine does not
start
Input inclination switch
B56
The machine cannot be
started, because the input
does not receive a signal
from the inclination switch
Wire breakage in current path
Switch defective
The switch is in actuated state
(incorrect installation position)
X3:23 1405
5091 Shut down of
diesel engine
Input inclination switch
B56
The diesel engine is shut
down because the input on
the control does not receive
a signal from the inclination
sensor
Wire breakage in current path
Switch defective
The switch is in actuated state
(machine has turned over) The
machine must first be shut
down after it has been placed
in correct position.
X3:23 1405
5092 Shut down of
diesel engine
Input inclination switch
B56
The diesel engine is shut
down because the input on
the control does not receive
a signal from the inclination
sensor
+ Start lock activated
The switch is in actuated state
(machine has turned over)
+ Start lock activated
Wire breakage in current path
Switch defective
X3:23 1405
Appendix – List of fault codes
D.ONE
178
