F 18
F F6C.GB 18-30 0504
Auger drive chains (12)
Only carry out maintenance work on the drive chains when the engine is switched off.
To check the chain tension:
- Manually turn both augers to the right and left. In this case, movement clearance at
the augers’ outer circumference should be 13-15 mm.
To re-tension the chains
- Loosen fastening bolts (12.1)
- Set the chain tension correctly using
the threaded pin (12.2):
- Tighten the threaded pins to 20 Nm
using a torque wrench.
- Subsequently loosen the threaded
pins again by one full revolution.
- Retighten the bolts (12.1).
Conveyor drive (13)
A lubricating nipple is positioned on the
left and right sides of the conveyor drive
housing.
12.1
12.1
12.2
13
