B 13
B F6C.GB 13-22 0504
4.3 Performance data
4.4 Traction drive/chassis
4.5 Engine
Basic width = min. paving width
(without cut-off shoes)
1.70 m
Working widths
- minimum paving width (with cut-off shoe)
- continuously adjustable up to
(for hydraulically adjustable screeds)
- maximum paving widths (with attachments)
1.10
3.40
4.40
m
Transportation speed 0 - 3,8 km/h
Working speed 0 - 32 m/min
Paving height 0 - 270 mm
Max. grain size 40 mm
Theoretical paving performance 300 t/h
Drive Hydrostatic drive, continuously controllable
Caterpillar drive
Two separately driven caterpillar drives with rubber
grouser chains.
Turning capacity Turning on the spot
Speed See above
Make/type Deutz BF4L 2011
Model 4-cylinder diesel engine (air-cooled)
Performance 50 kW / 68 hp (at 2300 rpm)
Volume of fuel tank See chapter F, „Maintenance“
