B 6
B F6C.GB 6-22 0504
3 Safety devices
Safe operation is only possible when all operating and control elements are function-
ing correctly and when all safety devices are in position.
Check the function of these devices at regular intervals (see chapter D, section
„Check list for the machine operator“).
3.1 Emergency stop button
- on the operating panel
- on the remote control units (
&
)
$
Pressing the emergency stop button switches the engine, the drives and the steering
system off. Corrective measures that might be necessary (anti-collision manoeuvres,
lifting the screed, etc.) are not possible in this case! Danger of accidents!
3.2 Steering
3.3 Horn
- on the operating panel
- on the two remote control units
3.4 Ignition key / lights
3.5 Safety devices on the gas heater system
- Bottle valve (1)
- Hose rupture protection (2)
- Main shut-off valve (3)
F0005_A1.EPS
F0069_A1.eps
Horn_Neu
Zünd_neu
Gas_VB340.tif
1
3
2
