Height adjustment and extension of augers: Height adjustment and extension of
augers ensure optimum adaptation to a wide range of paving thicknesses and widths.
In the basic version, the height is adjusted by means of barrel nuts.
Another variant allows the height to be regulated at the control panel by means of hy-
draulic cylinders (
&
).
Auger segments of different lengths can be attached to easily adapt to the different
paving widths.
Levelling/slope control system: The slope control system (
&
) allows the traction
point to be regulated at the left-hand or the right-hand side with a defined difference
to the opposite side.
To determine the actual value, the two traction arms are linked with a slope control
rod.
The slope control system always operates in conjunction with the screed height ad-
justment of the opposite side.
By adjusting the height of the traction point of the arm (traction roller), the paving
height of the material or the laying height of the screed can be controlled.
Actuation occurs electrohydraulically on both sides and can be controlled manually
by means of toggle switches or automatically by means of an electronic grade control
system. For further information, please refer to the operating instructions for „Level-
ling Systems“.
Screed lifting device: The screed lifting device is used to lift the screed during trans-
portation. Lifting occurs electrohydraulically on both sides by actuating the hydraulic
cylinders on the arms and is controlled by means of toggle switches on the operating
panel.
Control box for the screed heating system: Depending on version, the screed
heating system is controlled and monitored using a control box on the screed or on
the rear of the machine.
