F 16
F F6C.GB 16-30 0504
Outer auger bearing (9)
The lubricating nipples are located on
each side at the top of the outer auger
bearings.
These nipples must be lubricated each
time work is finished to force out any bi-
tumen residues that might have entered
and to supply the bearings with a fresh
filling of grease.
Apply 6 squirts of grease using a grease
gun.
If the auger is extended, the outer rings
should be loosened slightly when initially
greasing the outer bearing points in or-
der to improve ventilation on greasing.
The outer rings must be properly secured again after greasing.
New bearings must be filled with 60 squirts of grease using a grease gun.
F0139_A1.TIF
9
