D 28
D F6C.GB 28-50 0504
Emulsion spray system (80), (81)
Used to spray the parts coming into con-
tact with asphalt with a separator emul-
sion.
Two different variants are available:
A Spray bottle with pressure pump (80)
B Spray facility with electric pump (81)
&
$
Only switch on the spraying system
when the diesel engine is running; other-
wise, the battery will be discharged.
Switch off again after use.
Do not spray onto naked flames or hot
surfaces! Danger of explosion!
Collapsible roof lock (LH and RH on
the rear console) (82):
To lower the roof (e.g. during transport
on a low bed trailer):
- Release locking bolts (A) on both
sides
- Pull roof forwards at the frame
- Allow locking bolt (A) to engage in the
second detent bore.
Danger of crushing in the joint areas
A
B
EMUL1.TIF,EMUL2.TIF
81
80
BOHLSICH.TIF
82
A
