Dynapac F6C - External Starting (Starting Aid)

D 34
D F6C.GB 34-50 0504
External starting (starting aid)

The engine can be started with the help of an external power source if the batteries
are empty and the starter no longer turns.
Suitable power sources are:
- Other vehicles with a 24 V system;
- 24 V auxiliary battery;
- Start device that is suitable for external starting with 24 V/90 A.
$
Standard chargers or quick chargers cannot be used for external starting.
To externally start the engine:
- Set the drive lever (1) to the centre po-
sition and the speed adjuster (2) to
minimum.
- Turn the ignition key (3) to position „1“
to switch on the ignition.
- Use appropriate cables to connect the
external power source.
$
Observe the polarity! Always connect
the negative cable last and disconnect it
first!
- Press the starter (4) to start the en-
gine. Do not let the starter run perma-
nently for more than 10 seconds; allow
for a break of 1minute after every at-
tempt!
START
ON
OFF
Element2_F6C.cdr,
2
3
1
4
