3 Screed
The operating instructions for the screed cover all work required for mounting, setting
up and extending the screed.
4 Electrical connections
Establish the following connections when the mechanical components have been
mounted and set up:
4.1 Connect remote controls
- at the socket (17) (on the left and right
beneath the rear console).
4.2 Connect levelling system
- Connect the socket (on the left/right of
the rear console) for the automatic lev-
elling system/handset here if control is
to be carried out via the controller.
B0092A1.pic
17
18
