F 17
F F6C.GB 17-30 0504
Auger box filling level (11)
Only carry out maintenance work on the
drive chains when the engine is
switched off.
The auger box is equipped with a lifetime
grease filling.
In order to check the filling level:
- Remove the nuts (11.1) and remove
the closing cover (11.2).
The auger box should be filled with
grease up to the top edge of the lower
chain sprocket. (approx. 3.5 litres)
- If necessary, top grease up and seal
the auger box again properly.
11.111.2
