Dynapac F6C - Electric Fuses; Main Fuses (1); Fuses in the Main Terminal Box

F 28
F F6C.GB 28-30 0504
5 Electric Fuses
5.1 Main fuses (1)
5.2 Fuses in the main terminal box
Fuse board (2)
1.
- F3.1 Terminal box, overall electrics
- F3.2 not in use
50 A
No. F5.1 - F5.8 A
1. Hydraulic oil cooler fan 20
2. free 10
3. Screed heater prefuse 10
4. Starter 10
5. 1. Rear left socket 10
6. 2. Rear left socket, rotating beacon ( & )10
7. 1. Rear right socket 10
8. 2. Rear right socket 10
1
2
3
1 2
3 4 5 6
7
8
