Dynapac F6C - Electrical System; Gas Heating System for the Screed (O)

B 16
B F6C.GB 16-22 0504
4.11 Electrical system
4.12 Gas heating system for the screed (O)

For the filling volumes of lubricating and operating agents, see chapter F, „Mainte-
nance“.
On-board voltage 24 V
Batteries 2 x 12 V,72 Ah
Fuses See chapter F, section 5 „Electric fuses“
Fuel (liquefied gas) Propane gas
Gas bottles:
filling volume per bottle
gross weight per bottle
1 unit
70 l
33 kg
Operating pressure
(behind pressure reducer)
approx. 1.5 bar
Additional data See operating instructions for the screed
