4.3 Connect auger limit switches
- to socket (19)
(left/right on remote control)
4.4 Connect levelling device
- at the socket (20) (on the left/right on
the remote control).
4.5 Connect working lights
- to sockets (21) (on the paver finisher).
F0119_A1.TIF
19
20
21
