Dynapac F6C - Hydraulic System; Material Compartment (Hopper); Material Conveying

B 14
B F6C.GB 14-22 0504
4.6 Hydraulic system
4.7 Material compartment (hopper)
4.8 Material conveying
Pressure generation
- Hydraulic pumps via distribution gear
(flange-mounted directly on the engine)
Pressure distribution
Hydraulic circuits for:
- Travel drive
- Material conveying and distribution
- Screed tamper ( & ) / vibration
- Cylinder actuators for steering, hopper, levelling,
screed lifting, extending/retracting screed parts,
auger lift ( & )
Hydraulic oil reservoir - volume See chapter F, „Maintenance“
Volume
approx. 4.7 m
3
= approx. 10.1 t
Minimum inlet height, centre 465 mm
Minimum inlet height, outside 650 mm
Conveyors Left and right separately controllable
Drive
Standard: mech. limit switch
Option: ultrasonic sensors
Conveying volume controller
Fully automatic via configurable switching points
Standard mech. limit switch
Option: ultrasonic sensors
