D 15
D F6C.GB 15-50 0504
Item Designation Brief description
27
Levelling cylinder
left/right
For manually actuating the levelling cylinders when automatic
levelling is switched off.
Switch on the remote control must be set to „manual“.
28 not in use
29
Straight-ahead
travel synchronisa-
tion
This potentiometer is used to set straight-ahead travel to an
optimum setting while the vehicle is in motion in the event of
failure of the straight-ahead travel control function.
- Set the steering wheel to position “0”; then adjust the poten-
tiometer until the finisher is travelling straight ahead.
30
Turning on the
spot
Switch at the top position:
Normal position for straight-ahead travel.
If the switch has been inadvertently set to the bottom
position (with the steering wheel set to straight-ahead
travel), the finisher does not move. This is often inter-
preted as a ‘malfunction’.
Switch at the bottom position:
The finisher turns on the spot (the caterpillar chains run in oppo-
site directions) when the steering wheel is set to “10”.
Steering knob turned to the left = finisher turns to the left
Steering knob turned to the right = finisher turns to the right
When the finisher turns, persons and objects next to
the finisher are in extreme danger. Watch the area
where the finisher turns!
31
Retract/extend
push roller cross-
bar (O)
$
When this switch is actuated, the push roller crossbar
retracts or extends hydraulically.
To adapt to suit the infeed length of the material truck.
32 not in use
