EDR-3000 IM02602003E
LED Settings
LEDs group A
Device Parameters of the LEDs
Parameter Description Setting range Default Menu path
Latched Defines whether the LED will be latched when it picks up. Inactive,
Active
Active [Device Para
/LEDs
/LEDs group A
/LED 1]
Ack signal Acknowledgment signal for the LED. If latching is set to
active the LED can only be acknowledged if all signals
that initiated the setting of the LED are no longer present.
Dependency Only available if: Latched = Active
1..n, LEDAcknList -.- [Device Para
/LEDs
/LEDs group A
/LED 1]
LED Active Color The LED lights up in this color if the state of the OR-
assignment of the signals is true.
Green,
Red,
Red flash,
Green flash,
-
Red [Device Para
/LEDs
/LEDs group A
/LED 1]
LED Inactive Color The LED lights up in this color if the state of the OR-
assignment of the signals is false.
Green,
Red,
Red flash,
Green flash,
-
- [Device Para
/LEDs
/LEDs group A
/LED 1]
Assignment 1 Assignment 1..n, Assignment
List
51P[1].Trip [Device Para
/LEDs
/LEDs group A
/LED 1]
Inverting 1 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 1]
Assignment 2 Assignment 1..n, Assignment
List
-.- [Device Para
/LEDs
/LEDs group A
/LED 1]
www.eaton.com 129
