EDR-3000 IM02602003E
Standards
Approvals
UL-listed file: E154862
Design Standards
Generic Standard EN 61000-6-2 , 2005
EN 61000-6-3 , 2006
Product Standard EC 60255-1; 2009
IEC 60255-27, 2013
EN 50178, 1998
UL 508 (Industrial Control Equipment), 2005
CSA C22.2 No. 14-95 (Industrial Control Equipment),1995
ANSI C37.90, 2005
High Voltage Tests (IEC 60255-1)
High Frequency Interference Test
IEC 60255-22-1
IEEE C37.90.1
IEC 61000-4-18
class 3
Within one circuit
Circuit to ground
Circuit to circuit
1 kV/2 s
2.5 kV/2 s
2.5 kV/2 s
Insulation Voltage Test
IEC 60255-27 (10.5.3.2)
IEC 60255-5
EN 50178
All circuits to other circuits and exposed
conductive parts
Except interfaces
Voltage measuring input
2.5 kV (eff.)/50Hz, 1 min.
1.5 kV DC, 1 min.
3 kV (eff.)/50 Hz, 1 min.
Impulse Voltage Test
IEC 60255-27 (10.5.3.1)
IEC 60255-5
5 kV/0.5J, 1.2/50 µs
Insulation resistance test
IEC 60255-27 (10.5.3.3)
EN 50178
Within one circuit
Circuit to circuit
500V DC , 5s
500V DC , 5s
