EDR-3000 IM02602003E
DI-8P X
Name of the Assembly group:
DI-8P X1
Device Parameters of the Digital Inputs on DI-8P X
Parameter Description Setting range Default Menu path
Nom Voltage Nominal voltage of the digital inputs 24 V dc,
48 V dc,
60 V dc,
110/120 V dc,
230/240 V dc,
110/120 V ac,
230/240 V ac
110/120 V dc [Device Para
/Digital Inputs
/DI-8P X1
/Group 1]
Inverting 1 Inverting the input signals. Inactive,
Active
Inactive [Device Para
/Digital Inputs
/DI-8P X1
/Group 1]
Debouncing Time 1 A change of the state of a digital input will only be
recognized after the debouncing time has expired
(become effective). Thus, transient signals will not be
misinterpreted.
No Debouncing
Time,
20 ms,
50 ms,
100 ms
20 ms [Device Para
/Digital Inputs
/DI-8P X1
/Group 1]
Nom Voltage Nominal voltage of the digital inputs 24 V dc,
48 V dc,
60 V dc,
110/120 V dc,
230/240 V dc,
110/120 V ac,
230/240 V ac
110/120 V dc [Device Para
/Digital Inputs
/DI-8P X1
/Group 2]
Inverting 2 Inverting the input signals. Inactive,
Active
Inactive [Device Para
/Digital Inputs
/DI-8P X1
/Group 2]
www.eaton.com 64
