EDR-3000 IM02602003E
Assignment List
The »ASSIGNMENT LIST« below summarizes all module outputs (signals) and inputs (e.g.: states of the assignments).
Name Description
-.- No assignment
Prot.Available Signal: Protection is available.
Prot.Active Signal: Active
Prot.ExBlo Signal: External Blocking
Prot.Pickup Phase A Signal: General Pickup Phase A
Prot.Pickup Phase B Signal: General Pickup Phase B
Prot.Pickup Phase C Signal: General Pickup Phase C
Prot.Pickup IX or IR Signal: General Pickup - Ground Fault
Prot.Pickup Signal: General Pickup
Prot.Trip Phase A Signal: General Trip Phase A
Prot.Trip Phase B Signal: General Trip Phase B
Prot.Trip Phase C Signal: General Trip Phase C
Prot.Trip IX or IR Signal: General Trip Ground Fault
Prot.Trip Signal: General Trip
Prot.Res Fault a Mains No Signal: Resetting of fault number and number of grid faults.
Prot.ExBlo1-I Module Input State: External Blocking1
Prot.ExBlo2-I Module Input State: External Blocking2
Ctrl.Local Switching Authority: Local
Ctrl.Remote Switching Authority: Remote
Ctrl.SG Indeterm Minimum one Switchgear is moving (Position cannot be determined).
Ctrl.SG Disturb Minimum one Switchgear is disturbed.
Bkr.SI SingleContactInd Signal: The Position of the Switchgear is detected by one auxiliary contact (pole) only. Thus indeterminate
and disturbed Positions cannot be detected.
Bkr.Pos not CLOSE Signal: Pos not CLOSE
Bkr.Pos CLOSE Signal: Breaker is in CLOSE-Position
Bkr.Pos OPEN Signal: Breaker is in OPEN-Position
Bkr.Pos Indeterm Signal: Breaker is in Indeterminate Position
Bkr.Pos Disturb Signal: Breaker Disturbed - Undefined Breaker Position. The feed-back signals (Position Indicators) contradict
themselves. After expiring of a supervision timer this signal becomes true.
Bkr.Ready Signal: Breaker is ready for operation.
Bkr.Interl CLOSE Signal: One or more IL_Close inputs are active.
Bkr.Interl OPEN Signal: One or more IL_Open inputs are active.
Bkr.CES succesf Signal: Command Execution Supervision: Switching command executed successfully.
Bkr.CES Disturbed Signal: Command Execution Supervision: Switching Command unsuccessful. Switchgear in disturbed
position.
www.eaton.com 704
