EDR-3000 IM02602003E
RS485*
Master/Slave: Slave
Connection: 6 screw-clamping terminals RM 3.5 mm (138 MIL)
(terminating resistors internal)
The RS485 interface is realized via terminals. The communication cable has to
be shielded. The shielding has to be fixed at the screw that is marked with the
ground symbol (rear side of the device).
Fiber Optic*
Master/Slave: Slave
Connection:
ST-Plug
URTD-Interface*
Connection:
Versatile Link
*availability depends on device
www.eaton.com 652
