External Acknowledgments
Within the [Ex Acknowledge] menu, the User can assign a signal (e.g.: the state of a digital input) from the assignment
list that:
•Acknowledges all (acknowledgeable) LEDs at once;
•Acknowledges all (acknowledgeable) Output Relays at once; or
•Acknowledges all (acknowledgeable) SCADA signals at once.
Within the [Protection Para\Global Prot Para\TripControl] menu, the User can assign a signal that acknowledges a
pending trip command.
For details, please refer to the Trip Control section .
External Acknowledge Via PowerPort-E
•If PowerPort-E is not running, please start the application.
•If device data have not been downloaded recently, select »Receive Data From The Device« from the »Device« menu.
•Double click on the »Device Parameter« icon in the navigation tree.
•Double click on the »Ex Acknowledge« icon within the operation menu.
•In the working window, the User can now assign each signal that resets all acknowledgeable LEDs, a signal that
resets all Relay Outputs, a signal that resets the SCADA signals respectively, and a signal that acknowledges a
pending trip command.
www.eaton.com 197
1..n, Assignment List
Ack LED
1..n, Assignment List
Ack RO
1..n, Assignment List
Ack Comm
Ex Acknowledge.Ack LED
Ex Acknowledge.Ack RO
Ex Acknowledge.Ack Comm
