Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Single Line Diagram
The single line diagram includes the graphically description of the switchgear and its designation (name) as well as its
features (short circuit proof or not ...). For displaying in the devices software, the switchgear' designations (e. g. QA1,
QA2, instead of SG[x]) will be taken from the single line diagram (configuration file).
The configuration file includes the single line diagram and the switchgear properties. Switchgear properties and single
line diagram are coupled via the configuration file.
The default settings of the switchgears depend on the used Single Line. The shown default
values correspond to a Single Line with two circuit breakers and to isolating switches.
www.eaton.com 363
